MENCOM MIN-3MFP-6
MENCOM MIN Size I, Cordset, 3 Pole, Male Straight / Female Straight, 6 Ft, 13A, Yellow, PVC
Product Type Cables Component Type Cordset Mencom Series MIN Size I Connection Style N/A Pin Count 3 Gender Male/Female Extension Orientation Head 1 Male Straight Mating Thread / Type Head 1 7/8-16UN2 Coupling Thread Gender1 Female Orientation Head 2 Female Straight Mating Thread / Type Head 2 7/8-16UN2 Coupling Thread Gender2 Female Wire Gauge 16 Upper AWG N/A Lower AWG N/A Voltage Rating 600 Amperage Rating 13 Cable Length in meters 2 Cable Length in feet 6 Cable O.D. 0.51 Cable O.D. Range N/A Color Code North American Cable Jacket Material PUR Jacket Color Yellow Armored Cordsets N/A Mounting Thread N/A Mounting Style N/A Nut No Termination N/A Shell / Coupling Nut Material Nickel Plated Brass Shielding N/A Ethernet Cable Standard N/A Ground Wire Yes Gland Upper Range N/A Gland Lower Range N/A mcvhpin N/A Number of Ports N/A Accessories N/A IP Rating IP67 Weight (lbs.) 0.9500
