SCHUNK 304202
SCHUNK (304202) DPG+ 40-IS-EX Gripper; Stroke per jaw : 2.5 [mm]; Closing force : N/A [N]; Opening force : 165 [N]; Weight : 0.14 [kg]; recommended workpiece weight : 0.55 [kg]; Closing time : 0.03 [s]; Opening time : 0.05 [s]
SCHUNK Pneumatic Parallel Gripper, DPG-Plus series; Version : ATEX version; Stroke per jaw : 2.5 [mm]; Closing force : N/A [N]; Opening force : 165 [N]; min. spring force : 45 [N]; Weight : 0.14 [kg]; recommended workpiece weight : 0.55 [kg]; Fluid consumption double stroke : 5.5 [cm³]; min. operating pressure : 4 [bar]; max. operating pressure : 6 [bar]; Nominal operating pressure : 6 [bar]; min. air purge pressure : 0.2 [bar]; max. air purge pressure : 0.5 [bar]; Closing time : 0.03 [s]; Opening time : 0.05 [s]; max. admissible finger length : 40 [mm]; max. admissible weight per finger : 0.1 [kg]; Protection class IP : 67 ; min. ambient temperature : 5 [°C]; max. ambient temperature : 90 [°C]; Repeat accuracy : 0.01 [mm]; Cleanroom class ISO 14644-1 : 5 ; Moment Mx max. : 8 [Nm]; Moment My max. : 9 [Nm]; Moment Mz max. : 4 [Nm]; max. axial force Fz max. : 190 [N];
