SCHUNK 304221
SCHUNK DPG+ 64-2-EX Gripper; Stroke per jaw : 3 [mm]; Closing force : 470 [N]; Opening force : 500 [N]; Weight : 0.39 [kg]; recommended workpiece weight : 2.3 [kg]; Closing time : 0.04 [s]; Opening time : 0.04 [s]
SCHUNK Pneumatic Parallel Gripper, DPG-Plus series; Version : ATEX version; Stroke per jaw : 3 [mm]; Closing force : 470 [N]; Opening force : 500 [N]; min. spring force : N/A [N]; Weight : 0.39 [kg]; recommended workpiece weight : 2.3 [kg]; Fluid consumption double stroke : 10 [cm³]; min. operating pressure : 2.5 [bar]; max. operating pressure : 6 [bar]; Nominal operating pressure : 6 [bar]; min. air purge pressure : 0.2 [bar]; max. air purge pressure : 0.5 [bar]; Closing time : 0.04 [s]; Opening time : 0.04 [s]; max. admissible finger length : 50 [mm]; max. admissible weight per finger : 0.3 [kg]; Protection class IP : 67 ; min. ambient temperature : 5 [°C]; max. ambient temperature : 90 [°C]; Repeat accuracy : 0.01 [mm]; Cleanroom class ISO 14644-1 : 5 ; Moment Mx max. : 30 [Nm]; Moment My max. : 45 [Nm]; Moment Mz max. : 30 [Nm]; max. axial force Fz max. : 825 [N];
